OVERVIEW
Order code/Preferred parts
Order code
The order code is an 8-digit combination, consisting of letters and numbers
which describes the unique characteristics of a switch.
The following scheme gives an abstract on the composition of the order code:
Order code Snap switches (example)
Switch type (1. / 2. digit)
Electrical rating (3. digit)
Actuator shape (4. digit)
–
Terminals and ?xation pins (5. / 6. digit) Auxiliary actuator options (7. / 8. digit)
DR
1
P
–
AL
AO
Order code Keymodules (example)
Keymodule type
Contact/current material
Number of contacts/functions
–
Operating characteristics / Keysystem con?guration
Diode
Pins
(1. / 2. digit)
(3. digit)
(4. digit)
actuator force (5. digit)
(6. digit)
(7. digit)
(8. digit)
MX
1
A
–
1
1
N
M
Preferred parts
The product pages in this brochure contain for each product a list of most
common part numbers / preferred versions. The variants in this list are
usually those with a high availability and mostly ?exible order quantities,
which can be also found as a stocking item at our distributors
Generally we can produce any switch variant on a customer-speci?c basis.
But we kindly ask for your understanding that this may eventually cause
longer lead-times or the requirement for certain minimum order quantities.
The complete overview of all possible switch variants can be found in
the dedicated technical speci?cation for each product which we will be
pleased to provide you with on demand.
A checklist on the key parameters and requirements to identify the best
suitable product can be found on the fold-out page at the back cover.
Please also make use of this checklist by making a photocopy, ?ll it out
with your requirements and fax it to one of our regional of?ces on the back
cover. We will be pleased to advise you!
22
